国际口腔医学杂志 ›› 2021, Vol. 48 ›› Issue (3): 263-268.doi: 10.7518/gjkq.2021058

• 唇腭裂专栏 • 上一篇    下一篇

腭裂术后患者发音时表情扭曲与构音的关系研究

艾皮孜古丽·亚库普1(),亚尔肯·阿吉2,吴言辉1,路利丹1,许辉1()

  1. 1.新疆维吾尔自治区人民医院口腔颌面外科 乌鲁木齐 830001
    2.新疆维吾尔自治区人民医院口腔科 乌鲁木齐 830001
  • 收稿日期:2020-10-05 修回日期:2021-01-02 出版日期:2021-05-01 发布日期:2021-05-14
  • 通讯作者: 许辉
  • 作者简介:艾皮孜古丽·亚库普,医师,硕士,Email: 3294498465@qq.com
  • 基金资助:
    新疆维吾尔自治区自然科学基金(2015211C203)

Relationship between the facial grimace and articulation of patients with repaired cleft palate

Aipiziguli Yakupu1(),Yaerken Aji2,Wu Yanhui1,Lu Lidan1,Xu Hui1()

  1. 1. Dept. of Oral and Maxillofacial Surgery, People,s Hospital of Xinjiang Uygur Autonomous Region, Urumqi 830001, China
    2. Dept. of Stomatology, People,s Hospital of Xinjiang Uygur Autonomous Region, Urumqi 830001, China
  • Received:2020-10-05 Revised:2021-01-02 Online:2021-05-01 Published:2021-05-14
  • Contact: Hui Xu
  • Supported by:
    Natural Science Foundation of Xinjiang Uygur Autonomous Region(2015211C203)

摘要:

目的 研究腭裂术后存在腭咽闭合不全或腭瘘的患者在发音时面部表情扭曲与构音的关系。方法 选择98例腭裂术后腭咽闭合不全或有腭瘘且发音时有表情扭曲的患者,观察并记录患者发音时的面部表情扭曲情况。将表情扭曲根据部位分为鼻部扭曲和面部扭曲,根据构音方式及构音位置分别分析表情扭曲与构音的关系。结果 按构音方式分类,98例腭裂术后患者鼻部扭曲的发生率从高到低依次为塞音57.14%(56例)、擦音51.02%(50例)、塞擦音35.71%(35例),面部扭曲的发生率依次为塞音42.86%(42例)、擦音38.78%(38例)、塞擦音30.61%(30例);按构音位置分类,鼻部和面部表情扭曲的发生率最高为双唇音,最低为喉音,发其他辅音,包括舌尖中音、舌面后音、舌尖前音、舌根音和舌面音时均可出现。结论 腭裂术后患者发所有塞音、擦音和塞擦音等压力性辅音时都可以出现表情扭曲动作;发音方式相同的音,随发音部位后移,表情扭曲的发生率降低;辅音省略、代偿较严重的患者,少有表情扭曲动作发生。

关键词: 腭裂, 鼻漏气, 鼻部扭曲, 面部扭曲, 构音

Abstract:

Objective To investigate the correlation between articulation of pressure-sensitive phonemes and nasal/facial grimace of patients with repaired cleft palate. Methods This study included 98 patients of repaired cleft palate with nasal/facia during speech. Each patient underwent subjective speech assessment. The incidence and distribution of nasal/facial grimace during pressure-sensitive phonemes were summarized focusing on manners and places of articulation. Results The articulation manners of the highest incidence rate for nasal grimace were stops 57.14% (56 cases), fricati-ves 51.02% (50 cases), and affricates 35.71% (35 cases), whereas those for facial grimace were 42.86% (42 cases), 38.78% (38 cases), and 30.61% (30 cases). The articulation area of the highest incidence rate for nasal and facial grimace was bilabial, the lowest incidence rate was guttural, and other consonants, including lingua-palatal, blade-alveolar, alveolar, velar, and supradental. Conclusion Facial grimace is the most common speech disorder of patients with cleft palate, occurring in all stops, fricatives, and affricates. With the same articulation manners, the incidence of facial grimace decreased as the articulation places moved back. The children with severe consonant loss and compensation had minimal facial grimace.

Key words: cleft palate, nasal emission, nasal grimace, facial grimace, articulation

中图分类号:

  • R782.2+2

图1

鼻部扭曲(A、B)和面部扭曲(C、D)"

表 1

表情扭曲在不同发音方式的辅音中的发生情况"

构音方式 压力性辅音错误类型
[例数/发生率(%)]
表情扭曲类型
[例数/发生率(%)]
省略 代偿、替代 弱化 鼻部扭曲 面部扭曲
塞音 /b/ 11/11.22 1/1.02 50/51.02 46/46.94 29/29.59
/p/ 7/7.14 1/1.02 58/59.18 47/47.96 31/31.63
/d/ 19/19.39 6/ 6.12 43/43.88 33/33.67 22/22.45
/t/ 2/2.04 13/13.27 49/50.00 43/43.88 29/29.59
/g/ 26/26.53 12/12.24 55/56.12 28/28.57 19/19.39
/k/ 4/4.08 18/18.37 70/71.43 38/38.78 27/27.55
/q/ 9/9.18 0/0 64/65.31 37/37.76 24/24.49
擦音 /s/ 12/12.24 18/18.37 62/63.27 34/34.69 31/31.63
/z/ 19/19.39 25/25.51 47/47.96 26/26.53 21/21.43
/?/ 17/17.35 22/22.45 45/45.92 29/29.59 23/23.47
/h/ 2/2.04 0/0 26/26.53 11/11.22 5/5.10
/?/ 9/9.18 7/7.14 50/51.02 19/19.39 7/7.14
/x/ 3/3.06 9/9.18 54/55.10 21/21.43 18/18.37
塞擦音 /?/ 11/11.22 23/23.47 55/56.12 29/29.59 30/30.61
/?/ 30/30.61 16/16.33 49/50.00 22/22.45 28/28.57

表 2

面部表情扭曲在不同构音位置的辅音中的发生情况"

构音位置 表情扭曲类型[例数/发生率(%)]
鼻部扭曲 面部扭曲
双唇音 56/57.14 42/42.86
舌尖前音 45/45.92 33/33.67
舌尖中音 51/52.04 39/39.80
舌面音 38/38.78 33/33.67
舌面后音 48/48.98 35/35.71
舌根音 42/42.86 27/27.55
喉音 11/11.22 5/5.10
[1] Dubey AK, Prasanna SRM, Dandapat S. Detection and assessment of hypernasality in repaired cleft palate speech using vocal tract and residual features[J]. J Acoust Soc Am, 2019,146(6):4211.
doi: 10.1121/1.5134433
[2] Pai BCJ, Hung YT, Wang RSH, et al. Outcome of patients with complete unilateral cleft lip and palate: 20-year follow-up of a treatment protocol[J]. Plast Reconstr Surg, 2019,143(2):359e-367e.
doi: 10.1097/PRS.0000000000005216
[3] Mapar D, Khanlar F, Sadeghi S, et al. The incidence of velopharyngeal insufficiency and oronasal fistula after primary palatal surgery with Sommerlad intravelar veloplasty: a retrospective study in Isfahan cleft care team[J]. Int J Pediatr Otorhinolaryngol, 2019,120:6-10.
doi: 10.1016/j.ijporl.2018.12.035
[4] 亚尔肯·阿吉, 努尔麦麦提·尤鲁瓦斯, 许辉, 等. 基于HMM的维吾尔语腭裂患儿语音理解度评估方法[J]. 电脑知识与技术, 2017,13(1):200-203.
Yaerken AJ, Nuermaimaiti YLWS, Xu H, et al. Eva-luation of speech intelligibility for Uyghur children with cleft palate based on HMM[J]. Comput Knowl Technol, 2017,13(1):200-203.
[5] Ann K. Disorders of resonance and airflow seconda-ry to cleft palate and/or velopharyngeal dysfunction[J]. Semin Speech Lang, 2011,32(2):141-149.
doi: 10.1055/s-0031-1277716
[6] Hortis-Dzierzbicka M, Radkowska E, Stecko E, et al. Speech outcome in complete unilateral cleft lip and palate‒a comparison of three methods of the hard palate closure[J]. J Oral Rehabil, 2014,41(11):809-815.
doi: 10.1111/joor.12204 pmid: 24954716
[7] Sell D, Harding A, Grunwell P. P. GOS.SP.ASS.’98: an assessment for speech disorders associated with cleft palate and/or velopharyngeal dysfunction (revised)[J]. Int J Lang Commun Disord, 1999,34(1):17-33.
doi: 10.1080/136828299247595
[8] Oren L, Kummer A, Boyce S. Understanding nasal emission during speech production: a review of ty-pes, terminology, and causality[J]. Cleft Palate Craniofac J, 2020,57(1):123-126.
doi: 10.1177/1055665619858873
[9] Lipira AB, Grames LM, Molter D, et al. Videofluoroscopic and nasendoscopic correlates of speech in velopharyngeal dysfunction[J]. Cleft Palate Craniofac J, 2011,48(5):550-560.
doi: 10.1597/09-203
[10] Basta MN, Silvestre J, Stransky C, et al. A 35-year experience with syndromic cleft palate repair: operative outcomes and long-term speech function[J]. Ann Plast Surg, 2014,73(Suppl 2):S130-S135.
doi: 10.1097/SAP.0000000000000286
[11] Hufnagle K. Therapy techniques for cleft palate spee-ch and related disorders[J]. Cleft Palate Craniofac J, 2004,41(3):340.
pmid: 15151439
[12] 许辉, 亚尔肯·阿吉, 木合塔尔·霍加, 等. 维吾尔语腭裂语音测试词表对腭咽闭合不全患者辅音发音的评估价值[J]. 山东医药, 2017,57(26):94-97.
Xu H, Yaerken AJ, Muhetaer HJ, et al. The value of Uigur palatopharyngeal test words table for assess consonant articulationin of patients with palatopha-ryngeal insufficiency[J]. Shandong Med J, 2017,57(26):94-97.
[13] 亚尔肯·阿吉, 许辉, 木合塔尔·霍加. 腭裂语音理解度评估方法研究进展[J]. 中华实用诊断与治疗杂志, 2016,30(6):525-527.
Yaerken AJ, Xu H, Muhetaer HJ. Progress of evalua-tion approaches of cleft palate speech intelligibility[J]. J Chin Pract Diagn Ther, 2016,30(6):525-527.
[14] Hortis-Dzierzbicka M, Radkowska E, Fudalej PS. Speech outcomes in 10-year-old children with complete unilateral cleft lip and palate after one-stage lip and palate repair in the first year of life[J]. J Plast Reconstr Aesthetic Surg, 2012,65(2):175-181.
doi: 10.1016/j.bjps.2011.09.015
[15] 尹恒, 郭春丽, 石冰, 等. 大龄腭裂患者术前辅音构音特点的初步研究[J]. 华西口腔医学杂志, 2013,31(2):182-185.
Yin H, Guo CL, Shi B, et al. A preliminary study on the consonant articulation of older patients with cleft palate[J]. West China J Stomatol, 2013,31(2):182-185.
[16] 朱洪平, 孙勇刚, 王光和, 等. 腭裂儿童的辅音声学特点研究[J]. 现代口腔医学杂志, 1998,12(3):24-26.
Zhu HP, Sun YG, Wang GH, et al. Acoustic features of consonants articulated by children with cleft pala-te[J]. J Mod Stomatol, 1998,12(3):24-26.
[17] 蒋莉萍, 王国民, 杨育生, 等. 腭裂咽成形术后患者异常语音的发音特点研究[J]. 中国口腔颌面外科杂志, 2005,3(1):48-50.
Jiang LP, Wang GM, Yang YS, et al. The study on ar-ticulation characteristics of the patients after pharyn-goplasty[J]. China J Oral Maxillofac Surg, 2005,3(1):48-50.
[18] Aizenbud D, Nachmani A, Silberstein E, et al. Botulinum toxin injections for modulation of nasal and facial grimaces in a cleft lip and palate patient[J]. Plast Reconstr Surg, 2009,124(1):170e-172e.
doi: 10.1097/PRS.0b013e3181a83a5f
[19] Samoy K, Hens G, Verdonck A, et al. Surgery for velopharyngeal insufficiency: the outcomes of the University Hospitals Leuven[J]. Int J Pediatr Otorhinolaryngol, 2015,79(12):2213-2220.
doi: 10.1016/j.ijporl.2015.10.007
[20] 闵志云, 李峰, 张艳云, 等. 成年腭裂术后语音障碍患者辅音构音特点的研究[J]. 听力学及言语疾病杂志, 2018,26(5):496-500.
Min ZY, Li F, Zhang YY, et al. A study on the con-sonants characteristics of articulation disorders adults with repaired cleft palate[J]. J Audiol Speech Pathol, 2018,26(5):496-500.
[21] Cler MJ, Lien YS, Braden MN, et al. Objective measure of nasal air emission using nasal accelerometry[J]. J Speech Lang Hear Res, 2016,59(5):1018-1024.
doi: 10.1044/2016_JSLHR-S-15-0407
[22] Scarmagnani RH, Barbosa DA, Fukushiro AP, et al. Relationship between velopharyngeal closure, hypernasality, nasal air emission and nasal rustle in subjects with repaired cleft palate[J]. Codas, 2015,27(3):267-272.
doi: 10.1590/2317-1782/20152014145 pmid: 26222944
[23] Naran S, Ford M, Losee JE. What’s new in cleft pala-te and velopharyngeal dysfunction management[J]. Plast Reconstr Surg, 2017,139(6):1343e-1355e.
doi: 10.1097/PRS.0000000000003335
[24] Ruda JM, Krakovitz P, Rose AS. A review of the evaluation and management of velopharyngeal insufficiency in children[J]. Otolaryngol Clin North Am, 2012,45(3):653-669.
doi: 10.1016/j.otc.2012.03.005
[25] Pradel W, Senf D, Mai R, et al. One-stage palate repair improves speech outcome and early maxillary growth in patients with cleft lip and palate[J]. J Phy-siol Pharmacol, 2009,60(Suppl 8):37-41.
