Cone beam computed tomography and immunohistochemical staining for the diagnosis and differential diagnosis of periapical cysts

Meichang Huang(),Hongjie Jiang,Yaling Tang,Lihong Yao()

  1. State Key Laboratory of Oral Diseases & National Center for Stomatology & National Clinical Research Center for Oral Diseases & Dept. of Pathology, West China Hospital of Stomatology, Sichuan University, Chengdu 610041, China
  • Received:2024-06-17 Revised:2024-11-13 Online:2025-07-01 Published:2025-06-20
  • Contact: Lihong Yao E-mail:hmcscu@163.com;yaolihongsansan@126.com
  • Supported by:
    Clinical Research Project Funded by West China Hospital of Stomatology, Sichuan University(LCYJ-MS-202308)

RichHTML

1

PDF (PC)

6

Abstract:

Objective　This study aimed to investigate the diagnostic and differential diagnostic utility of cone beam computed tomography (CBCT) and immunohistochemical staining in distinguishing among periapical cysts, periapical granulomas, and odontogenic keratocysts. Methods　The clinicopathological and imaging data of 143 patients with periapical cysts and 45 patients with periapical granulomas were collected and analyzed. A total of 29 cases of paraffin-embedded periapical cysts and 24 cases of odontogenic keratocysts were selected. Immunohistochemical stai-ning for CK14, CK19, CD57, and Ki-67 was performed, and the relevant literature was reviewed. Results　The accuracy of CBCT in the diagnosis of periapical cyst was 68.5%, and the accuracy of CBCT in the diagnosis of periapical granuloma was 44.4%. However, CBCT diagnoses are inconsistent with the pathological results for periapical cysts and granulomas (Kappa<0.4). The accuracy of CBCT in the diagnosis of periapical cyst was related to the location of the lesion (P=0.033), residual epithelium (P=0.036), and foam cells (P=0.027) but not to cholesterol cleft, hemorrhage, calcification, acute and chronic inflammation, and the degree of inflammation (P>0.05). Expression of epithelial markers in periapical cysts and odontogenic keratocysts: CK14 and CK19 were positively expressed in most cases, and CD57 was negatively expressed. Expression of markers of cell proliferative activity: Ki-67 positivity in periapical cysts ranged from 1% to 3%, severe infection increased Ki-67 positivity to 15%, and Ki-67 positivity in odontogenic keratocysts ranged from 1% to 3% or 10% to 80%. Conclusion　The sensitivity of CBCT in the diagnosis of periapical cysts and periapical granulomas is good, but the specificity is poor. The accuracy of CBCT in the diagnosis of periapical cysts is related to the location of the lesion, residual epithelium, and foam cells but not to cholesterol cleft, hemorrhage, calcification, acute and chronic inflammation, and the degree of inflammation. The number of Ki-67-positive cells in patients with odontogenic keratocysts was higher than that in periapical cysts, and the positive cells were mainly located in the accessory basal cell layer.

Key words: periapical cyst, pathological diagnosis, cone beam computed tomography, immunohistochemical staining

CLC Number:

  • R781.34

TrendMD:

Tab 1

Comparison of pathology and CBCT diagnosis results"

诊断结果诊断方式χ2值P值
病理CBCT
根尖周囊肿1431234.6040.042
根尖周肉芽肿4565

Tab 2

Consistency analysis of CBCT and pathological diagnosis results"

病理学诊断结果CBCT诊断结果Kappa值P值
灵敏度/%特异度/%
根尖周囊肿68.544.40.1420.044
根尖周肉芽肿44.468.5

Fig 1

ROC curve for CBCT diagnosis"

Tab 3

The conformity of CBCT diagnosis of periapical cysts and its correlation with clinical pathological indicators"

临床病理指标病例数CBCT诊断根尖周囊肿结果P值
符合不符合
发病部位上颌前牙7961180.033
上颌后牙261412
下颌前牙1082
下颌后牙281513
上皮剩余有12570.036
无1319338
胆固醇裂隙有4231110.122
无1016744
泡沫细胞有363060.027
无1076839
出血有9162290.892
无523616
钙化有8354290.293
无604416
急慢性炎症有3221110.688
无1117734
炎症程度轻度4430190.946
中度362412
重度634414

Fig 2

IHC staining of periapical cysts SABC × 200"

Fig 3

IHC staining of odontogenic keratocyst SABC × 200"

1 Al Khasawnah Q, Hassan F, Malhan D, et al. Nonsurgical clinical management of periapical lesions using calcium hydroxide-iodoform-silicon-oil paste[J]. Biomed Res Int, 2018, 2018: 8198795.
2 Tsesis I, Krepel G, Koren T, et al. Accuracy for diagnosis of periapical cystic lesions[J]. Sci Rep, 2020, 10(1): 14155.
3 Howell FV, De la Rosa VM. Cytologic evaluation of cystic lesions of the jaws: a new diagnostic technique[J]. J South Calif Dent Assoc, 1968, 36(4): 161-166.
4 Cunningham CJ, Penick EC. Use of a roentgenographic contrast medium in the differential diagnosis of periapical lesions[J]. Oral Surg Oral Med Oral Pathol, 1968, 26(1): 96-102.
5 Cotti E, Schirru E. Present status and future directions: imaging techniques for the detection of periapical lesions[J]. Int Endod J, 2022, 55(): 1085-1099.
6 Giudice RL, Nicita F, Puleio F, et al. Accuracy of periapical radiography and CBCT in endodontic evaluation[J]. Int J Dent, 2018, 2018: 2514243.
7 Çalışkan MK, Kaval ME, Tekin U, et al. Radiographic and histological evaluation of persistent periapical lesions associated with endodontic failures after apical microsurgery[J]. Int Endod J, 2016, 49(11): 1011-1019.
8 Mirković S, Tadić, Durdević Mirković T, et al. Comparative analysis of accuracy of diagnosis of chronic periapical lesions made by clinical and histopatologi-cal examination[J]. Med Pregl, 2012, 65(7/8): 277-280.
9 Rosenberg PA, Frisbie J, Lee J, et al. Evaluation of pathologists (histopathology) and radiologists (cone beam computed tomography) differentiating radicular cysts from granulomas[J]. J Endod, 2010, 36(3): 423-428.
10 纪志勇, 张佳莉, 孟柳燕. 383例根尖周病变的临床病理系统性回顾与分析[J]. 口腔医学研究, 2013, 29(10): 978-979, 981.
Ji ZY, Zhang JL, Meng LY. Clinical and pathological analysis of 383 patients with periapcial lesions[J]. J Oral Sci Res, 2013, 29(10): 978-979, 981.
11 Bornstein MM, Lauber R, Sendi P, et al. Comparison of periapical radiography and limited cone-beam computed tomography in mandibular molars for analysis of anatomical landmarks before apical surgery[J]. J Endod, 2011, 37(2): 151-157.
12 Alotaibi O, Alswayyed S, Alshagroud R, et al. Evalua-tion of concordance between clinical and histopa-thological diagnoses in periapical lesions of endo-dontic origin[J]. J Dent Sci, 2020, 15(2): 132-135.
13 Sönmez G, Kamburoğlu K, Yılmaz F, et al. Versatility of high resolution ultrasonography in the assessment of granulomas and radicular cysts: a comparative in vivo study[J]. Dentomaxillofac Radiol, 2019, 48(6): 20190082.
14 Lizio G, Salizzoni E, Coe M, et al. Differential diagnosis between a granuloma and radicular cyst: effectiveness of magnetic resonance imaging[J]. Int Endod J, 2018, 51(10): 1077-1087.
15 Alam H, Sehgal L, Kundu ST, et al. Novel function of keratins 5 and 14 in proliferation and differentiation of stratified epithelial cells[J]. Mol Biol Cell, 2011, 22(21): 4068-4078.
16 Živković ND, Mihailović DS, Kostić MS, et al. Markers of proliferation and cytokeratins in the differential diagnosis of jaw cysts[J]. Ear Nose Throat J, 2017, 96(9): 376-383.
17 Shruthi DK, Shivakumar MC, Tegginamani AS, et al. Cytokeratin 14 and cytokeratin 18 expressions in reduced enamel epithelium and dentigerous cyst: possible role in oncofetal transformation and histogenesis- of follicular type of adenomatoid odontogenic tumor[J]. J Oral Maxillofac Pathol, 2014, 18(3): 365-371.
18 Aristizabal Arboleda P, Sánchez-Romero C, de Almeida OP, et al. Calcifying odontogenic cyst associa-ted with dentigerous cyst in a 15-year-old girl[J]. Int J Surg Pathol, 2018, 26(8): 758-765.
19 Heatley MK. Keratin expression in human tissues and neoplasms[J]. Histopathology, 2002, 41(4): 365-366.
20 Tsuji K, Wato M, Hayashi T, et al. The expression of cytokeratin in keratocystic odontogenic tumor, orthokeratinized odontogenic cyst, dentigerous cyst, radicular cyst and dermoid cyst[J]. Med Mol Morphol, 2014, 47(3): 156-161.
21 Silva LABD, Sá MAR, Melo RA, et al. Analysis of CD57+ natural killer cells and CD8+ T lymphocytes in periapical granulomas and radicular cysts[J]. Braz Oral Res, 2017, 31: e106.
22 Arai K, Yamamura S, Seki S, et al. Increase of CD57+ T cells in knee joints and adjacent bone marrow of rheumatoid arthritis (RA) patients: implication for an anti-inflammatory role[J]. Clin Exp Immunol, 1998, 111(2): 345-352.
23 Moreira PR, Santos DF, Martins RD, et al. CD57+ cells in radicular cyst[J]. Int Endod J, 2000, 33(2): 99-102.
24 Gerdes J, Lemke H, Baisch H, et al. Cell cycle analy-sis of a cell proliferation-associated human nuclear antigen defined by the monoclonal antibody Ki-67[J]. J Immunol, 1984, 133(4): 1710-1715.
25 Martins CA, Rivero ER, Dufloth RM, et al. Immunohistochemical detection of factors related to cellular proliferation and apoptosis in radicular and dentigerous cysts[J]. J Endod, 2011, 37(1): 36-39.
26 Mourão RVC, Pinheiro Júnior EC, Barros Silva PG, et al. Study of the relationship between mononu-clear inflammatory infiltrate and Ki-67 and basement membrane and extracellular matrix protein expression in radicular cysts[J]. Int Endod J, 2016, 49(5): 447-453.
27 Ayoub MS, Baghdadi HM, El-Kholy M. Immunohistochemical detection of laminin-1 and Ki-67 in radicular cysts and keratocystic odontogenic tumors[J]. BMC Clin Pathol, 2011, 11: 4.
28 Suzuki T, Kumamoto H, Kunimori K, et al. Immunohistochemical analysis of apoptosis-related factors in lining epithelium of radicular cysts[J]. J Oral Pathol Med, 2005, 34(1): 46-52.
29 张权, 郑乾坤, 马会青, 等. Bcl-6和ICOS在根尖周囊肿与根尖周肉芽肿中的表达[J]. 解剖学杂志, 2019, 42(2): 128-131.
Zhang Q, Zheng QK, Ma HQ, et al. Expression of B cell lymphoma 6 and inducible costimulator in periapical cysts and periapical granulomas[J]. Chin J Anatom, 2019, 42(2): 128-131.
30 Peng YQ, Liu L, Li XF, et al. B cells at the core: immune mechanisms and therapeutic potentials in periapical lesions[J]. J Endod, 2025, 51(1): 4-14.
31 王海丞, 章燕. 根尖周囊肿囊壁成纤维样细胞中纤维粘连蛋白基因可变剪接片对诱导破骨细胞形成[C]//中华口腔医学会口腔生物医学专业委员会. 2019第九次全国口腔生物医学学术年会论文汇编. 同济大学附属口腔医院上海牙组织修复与再生工程技术研究中心, 2019: 72.
Wang HC, Zhang Y. Alternative splicing of fibronectin gene in fibroblast like cells of periapical cyst wall induces osteoclast formation[C]//Chinese Socie-ty of Stomatology Oral Biomedical Professional Committee. Compilation of Papers from the 9th National Oral Biomedical Academic Annual Confe-rence in 2019. Tongji University Affiliated Stomatological Hospital, Shanghai Dental Tissue Restoration and Regeneration Engineering Technology Research Center, 2019: 72
32 Shen SQ, Wang R, Huang SG. Expression of the stem cell factor in fibroblasts, endothelial cells, and macrophages in periapical tissues in human chronic periapical diseases[J]. Genet Mol Res, 2017, 16(1). doi: 10.4238/gmr16019394 .
doi: 10.4238/gmr16019394
33 Yang JW, Jiang JH, Wang HC, et al. The extra domain A of fibronectin facilitates osteoclastogenesis in radicular cysts through vascular endothelial growth factor[J]. Int Endod J, 2020, 53(4): 478-491.[34] SheethalHS, KnH, SmithaT, et al. Role of mast cells in inflammatory and reactive pathologies of pulp, periapical area and periodontium[J]. J Oral Maxillofac Pathol, 2018, 22(1): 92-97.[35] LiuCY, WangHC. The fibroblast of radicular cyst facilitate osteoclastogenesis via the autocrine of fibronectin containing extra domain A[J]. Oral Dis, 2019, 25(4): 1136-1146.
36 张梅华, 于蕴之, 缪羽. 破骨细胞核因子κB受体活化因子配体和骨保护素在根尖周囊肿和肉芽肿中的表达及意义[J]. 华西口腔医学杂志, 2012, 30(4): 360-363.
Zhang MH, Yu YZ, Miao Y. The expression and significance of receptor activator of nuclear factor kappa B ligand and osteoprotegerin in periapical cyst and periapical granuloma[J]. West China J Stomatol, 2012, 30(4): 360-363.
37 Brito LNS, de Lemos Almeida MMR, de Souza LB, et al. Immunohistochemical analysis of galectins- 1, -3, and-7 in periapical granulomas, radicular cysts, and residual radicular cysts[J]. J Endod, 2018, 44(5): 728-733.
